Introducing the Inspectara VideoGuard 1080, a high-performance Under Vehicle Surveillance System (UVSS) designed for fixed installations in the most demanding environments.
Equipped with a 2-megapixel resolution and a waterproof design, the VideoGuard 1080 delivers real-time video output with high-resolution imaging up to full 1080p.
This system supports the standard Onvif protocol for seamless integration with existing security infrastructures. Its powerful LED illuminator ensures clear visibility under all weather conditions, making it an ideal solution for continuous,
reliable under-vehicle inspections.
The Inspectara VideoGuard 1080 stands out with its real-time video capabilities, high resolution, and robust design, offering a reliable solution for high-security environments.
Key Features:
- Fixed Installation: Designed for permanent security checkpoints.
- Real-Time Video Output: Provides immediate, live surveillance.
- High-Resolution Imaging: Captures detailed images up to full 1080p.
- 2-Megapixel Resolution: Ensures high-quality visual output.
- Waterproof Design: Built to withstand harsh environments.
- Support for Standard Onvif Protocol: Allows easy integration with other security systems.
- Powerful LED Illuminator: Ensures visibility in all weather conditions.
Specifications:
| Electrical and Mechanical Specifications | |
|---|---|
| Ethernet | RJ-45(10/100Base-T) |
| Protocol | IPv4/IPv6,HTTP,TCP/IP,UDP,NTP,DHCP,DNS |
| Interoperability | CGI,Onvif |
| Max.User Access | 20 |
| Power Supply | POE+(802.3at) |
| Power Consumption | 17 W |
| Operating Temperature | ‘-30°F to 140°F ; -30℃~+60℃ Less than 95% RH |
| IP Rating | IP68 |
| Dimensions | 420mm x 320mm x 100mm |
| Net Weight | 12 Kg |
| Camera Specifications | |
|---|---|
| Compression | H.265/H.264M/H.264H/H.264B |
| Resolution | 1080P(1920*1080) |
| Frame Rate | 1080P(1~25/30fps) |
| Bit Rate Control | CBR VBR |
| Bit Rate | H.264:80kbps~10Mbps |
| Day/Night | Auto(ICR)/Color/B/W |
| BLC Mode | BLC,HLC,WDR(140db) |
| White Balance | Auto/Manual |
| Gain Control | Auto/Manual |
| Noise Reduction | 3D |
| Smart IR | Smart IR |
| Audio Interface | Input/Ouput 1 Input/1 Ouput |
| RS485 | N/A |
| Alarm | 2/1 channel In/Out |
